LAWO Edge One
Compact stagebox for Pro AV and broadcast application
LAWO Edge One
Compact stagebox for Pro AV and broadcast application
Description
Edge One makes the I/O part of Pro AV and broadcast workflows highly flexible by providing combined connectivity and functionality for both video and audio, allowing users to do more with less. As a HOME-native ST2110 unit that supports NMOS, Edge One is one of a kind: it provides analog, MADI and USB audio, video connectivity on HD-BNC and HDMI, a 32 x 16 audio mixer with audio DSP, video frame sync, JPEG XS encoding and decoding, and a lot more. It also includes power over Ethernet and the possibility to use it locally without IP if that doesn’t add anything.
Product highlights:
- Up to 8x analog audio connectors (XLR) with Lawo-quality preamps
- Up to 8x SDI connectors (micro HD-BNC, bidirectional)
- Up to 4x HDMI ports (two outputs, two inputs/outputs)
- 2x MADI ports with sample rate conversion as standard
- USB-C port supporting four input and output audio channels
- Synchronization and reference connectors
- 2x Ethernet (with PoE++) and 2x SFP connectors for IP networks
- GPI I/O port (2 in, 4 out)
